Obl - XLB25.50MMA40DVFAST
| Manufacturer | Obl |
|---|---|
| Part Number | XLB25.50MMA40DVFAST |
| Inner Code | 3748774 |
| Technical specification | DOSING PUMP,XLB25.50MMA40DVFAST,OBL; PUMP WITHOUT ELECTRICAL MOTOR; PUMP MANUFACTURER: OBL; PUMP MODEL: XLB25.50MMA40DVFAST; PUMP S/N: 2012P10543, 2012P10544; PUMP WITH LOCAL VISUAL DIAPHRAGM BURST INDICATOR VIA PRESSURE GAUGE AND ¼" NPT CONNECTION FOR REMOTE INSTRUMENT; PUMP TYPE: DIAPHRAGM; RATED CAPACITY: 105 L/HR; SPEED (STROKES/MIN) 40; PUMP HEAD: HYDRAULIC; MAXIMUM DISCHARGE PRESSURE: 23 BARG; MINIMUM DISCHARGE PRESSURE: 18 BARG; HYDRO TEST PRESSURE: 60 BARG; MAX KW BASIS GEAR STRENGTH: 1.5 KW; SUCTION AND DISCHARGE CONNETION: 1/2"", ANSI 300#, R.F; SUCTION POSITION BOTTOM; DISCHARGE POSITION: TOP; VALVES SUCTION/DISCHARGE TYPE AND NO: BALL, 2 NOS/ BALL 2 NOS; LIQUID NAME (TYPE): RP6000Q; LIQUID MAX TEMPERATURE: 85°C; LIQUID END MATERIAL: SS316L; HYDRAULIC AND PROCESS DIAPHRAGM MATERIAL: PTFE; MATERIAL FOR VALVE , SEAT, GUIDE, BODY: SS316L; VALVE GASKET MATERIAL: FPM (FLUOROELASTOMER); FRAME MATERIAL: CAST IRON; PROCESS PIPING: SS316L.; RELIEF VALVE SETTING INTERNAL/EXTERNAL: 23 BARG. |
| Weight | 1 |
Please contact us to request a price quote for Obl - XLB25.50MMA40DVFAST, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
