Obl - LK80 AC 52102 FA
| Manufacturer | Obl |
|---|---|
| Part Number | LK80 AC 52102 FA |
| Inner Code | 3182976 |
| Description | Pump |
| Technical specification | Mechanical Hydraulic Piston Metering Pump with E - motor, API 675 STD Pressure Head: Stainless Steel 316L Piston: Ceramic Piston Seals: PTFE Piston Stroke: 30mm Valve Balls: Pyrex (Glass) Valve Seats: Incoloy 825 O-ring seals: Viton Suction - and discharge ports: ANSI Flanges 1 1/2" Spring Return mechanism, manual adjustment with micro scale and knob from 0-100%, max. delivery 850,0 liter / hour, max. outlet pressure 7,0 bar. Internal Pressure Release Valve: adjusted at 10 bar Motor 230 / 400 Volt, 50 Hz, 0,75 kW, 3 ph, IE2 |
| Weight | 45 |
Please contact us to request a price quote for Obl - LK80 AC 52102 FA, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
