Noris - FMN6-1-11-K
| Manufacturer | Noris |
|---|---|
| Part Number | FMN6-1-11-K |
| Inner Code | 5036533 |
| Description | transducer |
| Technical specification | programmable for frequency programmable frequency/voltage converter for speed measurement. Operation of the device via four short-stroke buttons and 3x16 character display Key features: . Measurement of one or two speeds . Additional determination of direction of rotation or slippage (or speed offset) . Adjustable offset for speed range monitoring . Adjustable range for moving averaging . Two galvanically isolated short-circuit-proof analog outputs . Variable output ranges: 0.. 5V, 0.. 10V, 2.. 10V, +/-5V, +/-10V, 0.. 20mA, 4.. 20mA . 6 potential-free relay outputs, 3 of which are programmable . Status LEDs . Line break monitoring of pick-up inputs . Automatic pick-up type recognition (PNP, NPN or counteract or push-pull) Integrated display for parameterization, value and status indicator Self-test for checking and parameterizing Wide range of applications due to the possibility of a flexible parameterization Easy installation (DIN rail) Power supply: 24V +30/ -25% Classification: GL, LROs, DNV, BV, ABS |
Please contact us to request a price quote for Noris - FMN6-1-11-K, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
