Nord - SK92072.1AM-71LP/4 BRE5 TF
| Manufacturer | Nord |
|---|---|
| Part Number | SK92072.1AM-71LP/4 BRE5 TF |
| Inner Code | 4642313 |
| Description | helical bevel geared motor |
| Technical specification | as delivered with s/n 202044983-100 but motor in IE3 *************************************************************************** Product name helical bevel geared motor Engine speed 1,405 rpm Translation 7.58 output speed 185,000 rpm Operating factor 3.80 Output torque M2 (Nm) 19.10 Max. downforce. M2 max. (Nm) 72.00 Power (kW) 0.370 Voltage (V) 230/400 frequency (Hz) 50 efficiency class IE3 operating mode S1 Degree of protection motor IP55 insulation class F Rated current 1 (AMP) 1.58 Rated current 2 (AMP) 0.91 cosine 1 0.76 M4 gearbox design Inclined design M4-75-M1 housing type hollow shaft shaft dimension 25H7 venting pressure venting Gripmaxx shrink disc Shrink disc location Shrink disc at B Thermal motor protection PTC thermistor, 3x155°C Star switching type Terminal box location/cable entry 1/I Braking torque (Nm) 5 Precima brake supplier brake voltages 400VWS-180VGS Degree of protection brake IP55 Brakes Series BR55PW Incremental encoder Preb. for encoder attachment (Kübler) Lubricant type mineral oil ISO VG 220 class oil CLP 220 Painting instructions Without painting CE logo yes CCC logo no Mexico Certificate NOM No UL no CSA no DoE CC no CSA ev no Alto Rendimento no Korea Energy Label No loose part clamp ring/bush Gripmaxx shrink disc |
Please contact us to request a price quote for Nord - SK92072.1AM-71LP/4 BRE5 TF, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
