Nord - SK9052.1AZSH-132SP/4 TF
| Manufacturer | Nord |
|---|---|
| Part Number | SK9052.1AZSH-132SP/4 TF |
| Inner Code | 3814884 |
| Description | Conical helical gear motor |
| Technical specification | Product name bevel helical geared motor Engine speed 1,465 rpm Translation 44.96 Output speed 33,000 1 / min Service factor 3.00 Output torque M2 (Nm) 1,612.00 Max. Output torque M2 max. (Nm) 4,800.00 Power (kW) 5,500 Voltage (V) 230/400 Frequency (Hz) 50 Efficiency class IE3 Operating mode S1 Motor protection class IP66 Insulation class F Nominal current 1 (AMP) 18.90 Nominal current 2 (AMP) 10.90 Cosine 1 0.80 M5 gearbox design Housing type hollow shaft flange-B14 Shaft dimension 70H7 Vent Pressure vent Cover hood cover f. Shrink disk Position of the cover hood at A Oil sight glass Oil sight glass Position of the oil sight glass on the E side Shrink disk With shrink disk Position of the shrink disk at A Thermal motor protection PTC thermistor, 3x155 ° C Connection type star Terminal box position / cable insert 2 / I Terminal box potted Yes Type of lubricant mineral oil ISO VG 220 Class oil CLP 220 Lubricant quantity (l) 11,500 Color 7031 blue-gray Paint type solid paint Painting instructions old painting 2 Painting instructions Basic (2) Type / terminal block GTS + MTS + KK Std (VA) CE logo yes CCC Logo No. UL no CSA no DoE CC No. CSA ev no Alto Rendimento No. Korea Energy Label No. Loose part cover Shrink disk |
| Weight | 1 |
Please contact us to request a price quote for Nord - SK9052.1AZSH-132SP/4 TF, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
