Nord - SK8382ABG-132MP/4 BRE100 HL TF
| Manufacturer | Nord |
|---|---|
| Part Number | SK8382ABG-132MP/4 BRE100 HL TF |
| Inner Code | 5038118 |
| Description | flat gear brake motor |
| Technical specification | Product name Flat gear brake motor Engine speed 1.460 rpm Translation 185.66 Levels 3 Output speed 7,900 rpm Operating factor 1.40 Output torque M2 (Nm) 9,107.00 Power (kW) 7,500 Voltage (V) 400/690 Frequency (Hz) 50 Efficiency class IE3 S1 operating mode Motor protection class IP55 Insulation class F Rated current 1 (AMP) 15.70 Rated current 2 (AMP) 9.10 Cosine 1 0.77 M6 gearbox design Housing type hollow shaft 100H7 wave measure Venting Pressure venting Viton gearbox shaft seal Rubber Buffer With Rubber Buffer Fastener With fastener Thermal motor protection cold conductor, 3x155°C Circuit type triangle Terminal box/cable entry with 4/I Braking torque (Nm) 100 400VWS-180VGS brake voltages Precima brake supplier Manual ventilation With manual ventilation Handheld ventilation position 4 IP55 brake protection class BR55PW Brake Series Engine shaft seal FKM (Viton) sealing ring Lubricant type Synth. ISO VG 220 oil CLP PG 220 oil grade Lubricant quantity (l) 30,000 Color 7031 Blue Gray Paint type solid color Basic painting instruction (2) CE logo Yes CCC logo No Mexico NOM certificate No UL No CSA No DoE CC No CSA ev No Alto Rendimento No Korea Energy Label No Loose part mounting element rubber buffer/met rubber manual ventilation lever |
Please contact us to request a price quote for Nord - SK8382ABG-132MP/4 BRE100 HL TF, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
