Nord - SK42125AFSH VL-160MP/4 TF
| Manufacturer | Nord |
|---|---|
| Part Number | SK42125AFSH VL-160MP/4 TF |
| Inner Code | 4893766 |
| Description | Helical screw motor |
| Technical specification | Engine speed 1.465 rpm Translation 18.80 Levels 2 Output speed 78,000 rpm Operating factor 1.20 Output torque M2 (Nm) 1,218.00 Power (kW) 11,000 Voltage (V) 400/690 Frequency (Hz) 50 Efficiency class IE3 S1 operating mode Motor protection class IP55 Insulation class F Rated current 1 (AMP) 20.50 Rated current 2 (AMP) 11.80 Cosine 1 0.85 Ambient engine temperature -20... +45°C M5 gearbox design Housing type hollow shaft flange B5 Bearing version VL 60H7 wave measure Flange diameter (mm) 450 Flange end flange at A Venting Pressure venting Viton gearbox shaft seal Cover cover for shrink disc Position of the cover cover at B Oil level measurement oil gauge Location oil gauge glass E-side Shrink Washer With Shrink Washer Position of the shrink disk Shrink disc at B Thermal motor protection cold conductor, 3x155°C Circuit type triangle Terminal box/cable entry with 2/I Lubricant type Synth. ISO VG 680 oil CLP PG 680 oil grade Lubricant quantity (l) 6,500 Hue 5010 gentian blue Paint type solid color NSDC3 painting instruction (3.4) CE logo Yes CCC logo No Mexico NOM certificate No UL No CSA No DoE CC No CSA ev No Alto Rendimento No Korea Energy Label No Looteil cover shrink disk Cable screw connection + O-ring 18504026+O-ring M40 |
Please contact us to request a price quote for Nord - SK42125AFSH VL-160MP/4 TF, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
