Nord - SK52F-160MP/4 BRE100 FHL MIK SR TF R
| Manufacturer | Nord |
|---|---|
| Part Number | SK52F-160MP/4 BRE100 FHL MIK SR TF R |
| Inner Code | 4709033 |
| Description | helical gear motor |
| Technical specification | Design: as already delivered with serial number 202373685-200, but with motor in IE3 (energy efficiency class) - - - - - - - - - - - - - - - - - - - - - - - - Product name helical gear motor Motor speed 1.465 rpm Translation 14.00 Output speed 105,000 rpm Operating factor 1.90 Output torque M2 (Nm) 1,004.00 Power (kW) 11,000 Voltage (V) 400/690 Frequency (Hz) 50 Efficiency class IE3 S1 operating mode Motor protection class IP55 Insulation class F Current Rating 1 (AMP) 20.50 Current Rating 2 (AMP) 11.80 Cosine 1 0.85 M4 gearbox design M4-20-M1 Inclined Design Housing type Flange B5 Wave size 55X110 Flange diameter (mm) 300 Open vent, with transport lock Oil balance/oil level tank Oil compensation tank Thermal motor protection cold conductor, 3x155°C Circuit type triangle Condensation water borehole Condensed water borehole Terminal box layer/cable insert 1/I Canopy/textile fan Double fan shroud Braking torque (Nm) 100 Brake voltages 400VWS-180VGS Precima brake supplier Manual ventilation With adjustable hand ventilation Position of the hand vent 2 Micro switch for brake Micro switch for ventilation function Rust/ dust-proof dust-/ rust-proof brake version Brake protection class IP55 BR55PW Bremse Series SSG fast switching rectifier (voltage evaluation) Lubricant type mineral oil ISO VG 220 Oil grade CLP 220 Colour 5010 gentian blue Paint type solid color Painting specification NSD4 (3.2) Additional work sealing Location/number of nameplate Second Getr.TS loose CE logo Yes CCC logo No Mexico NOM certificate No UL No CSA No DoE CC No CSA ev No Alto Rendimento No Korea Energy Label No Lot part 2. Transmission type plate hand ventilation lever oil expansion tank |
Please contact us to request a price quote for Nord - SK52F-160MP/4 BRE100 FHL MIK SR TF R, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
