Micro Detectors / Diell - SSC/LN-0A
| Manufacturer | Micro Detectors / Diell |
|---|---|
| Part Number | SSC/LN-0A |
| Inner Code | 1295314 |
| Technical specification | Nominal sensing distance 5m Thermal drift of Sr ≤10% Sr Repeat Accuracy 5% Sensitivity adjustment No Application Function Principle Retroreflective Notes with RL100 retro reflector Optic position Axial Outputs Output type PNP Output Function LO/DO selectable Switching frequency 250Hz Electrical data Operating Voltage 10-30Vdc No-Load supply current ≤30mA Load current ≤100mA Leakage current ≤10μA Output voltage drop 1,2Vmax. IL =100 mA Max ripple content 10% LED indicators Yellow (output state) Time delay before availability ≤200ms Short-circuit protection Yes Reverse Polarity Protection Yes Emission Infrared (880 nm) Interference to external light 3000lux (incandescent lamp), 10000lux (sunlight) Impulsive Overvoltage Protection Yes |
| Weight | 0.5 |
Please contact us to request a price quote for Micro Detectors / Diell - SSC/LN-0A, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
