Mdexx - 2LL1504-2AA13-7DD0
| Manufacturer | Mdexx |
|---|---|
| Part Number | 2LL1504-2AA13-7DD0 |
| Inner Code | 4450462 |
| Description | Fan |
| Custom Code | 84145995 |
| Technical specification | Material: 22326315 Size: 1PQ8 31 Fan design: radial Special version: - Increased AH 1500m above sea level - KT55°C Impeller: powder-coated sheet steel RAL7032 Drawing number: VZF4408-10 Design: according to ERP DVO 327 Motor: 230VD/400VY 50Hz; 460VY@ 60Hz Engine: IP55 RAL7030 Coating: 2K EP METAL BASE SG64-301273 Colour steel parts: RAL7032 Mounting material: galvanised Operating data 50Hz: vpkt=1.05M^3/s Pt=301Pa pl=0.71kW Operating data 60Hz: vPkt=1.32M^3/s Pt=408Pa pl=1.32kW Technical delivery conditions according to DIN24166, accuracy class 2 Tolerances to electrical specifications according to DIN EN 60034 vibrations according to ISO14694 impact and vibration category: BV3 |
Please contact us to request a price quote for Mdexx - 2LL1504-2AA13-7DD0, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
