Leybold - Ruvac-WAU501
| Manufacturer | Leybold |
|---|---|
| Part Number | Ruvac-WAU501 |
| Inner Code | 4916749 |
| Description | pump |
| Technical specification | Roots Vacuum Pump Important: IE3 motor protection switches are required Features: Robust roots vacuum pump for industrial use Bypass line for safe air pressure trigger Certified for ATEX 3G IIC TX (internal) 50 Hz II 3/-G Ex and IIC T4... T2 Gc 12°C < Ta< 40°C Technical data: Nominal flow rate: 505 m³/h Max. pumping speed: 606m³/h Max. allowable pressure difference: 80 mbar at 3000min-1, in continuous cycle Integral loss: <5x10-4 mbar l/s Permissible ambient temperature: 5-40°C Weight: 133 kg Dimensions (LxWxH): 830x310x340 Noise level at final pressure: <67 dB (A) Lubricating oil: LVO 130 Nominal power: 2.2 kW Efficiency class: IE3/ePACT Protection class: IP55 Supply voltage: 380-400V, 50Hz/380-480V, 60Hz “380-400V /50Hz (IE3); 416-480V /60Hz (ePACT)” 200-240V/50Hz: 200-240V/60Hz 200V/50Hz (IE3): 208-240V/60 Hz (ePACT) Nominal speed: 3000 rev/min-1 (50Hz)/3600 rev/min-1 (60Hz) Max. admissible speed: 3600 rev/min-1 Inlet connection flange: DN 63 ISO-K Exhaust connection flange: DN 63 ISO-K Pay attention to the different allowable pressure differences for different operating conditions as indicated in the operating instructions Supply limit: Leybonol LVO130 lubricating oil in separate packaging DN63 mesh Instructions for use |
Please contact us to request a price quote for Leybold - Ruvac-WAU501, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
