Leybold - 11296 / TRIVAC D65B
| Manufacturer | Leybold |
|---|---|
| Part Number | 11296 / TRIVAC D65B |
| Inner Code | 31103 |
| Description | Rotary vane vacuum pump |
| Custom Code | 84141025 |
| Technical specification | Features: Oil-sealed vacuum pump with integrated oil pump for Forced lubrication of the bearings even at high suction pressures of 1013 mbar. The pump is free of non-ferrous metals and the inner part of the pump is metallically sealed, i.e. no use of elastomer Seals that can be chemically attacked. The TRIVAC B The pump has a hydropneumatic suction pipe valve for vacuum protection and via a gas ballast device with which it It is possible to pump condensable vapors. ATEX certification of the pump in accordance with EU Directive 2014/34/EU in The Equipment group II, category 3 without ATEX certified motor ATEX II 3/-G Exh IIC T4 (50Hz) Gc ATEX II 3/-G Exh IIC T3 (60Hz) Gc 12°C<Ta< 40°C As intended, the vacuum pump must not be used in an explosion operate in a hazardous environment. Engine certification: CSA, UR Pump certification: CE, ATEX 3i RoHS compliant Technical data: Suction rate in accordance with DIN 28400:65 m³/h (50 Hz)/78 m³/h (60 Hz) Final partial pressure without gas ballast: 10-4 mbar Total ultimate pressure with gas ballast: < 5·10-3 mbar Sound level in accordance with DIN 45 635 with/with gas ballast: 57/ 59 dB (A) Dimensions (LxWxH): 797 x 235 x 357 mm Oil filling min/max: 2.0/3.3 l Includes oil filling with LVO 100 Motor data: Rated power of the three-phase motor 2.2 kW Rated speed: 1460 min-1 (50 Hz)/1760 min-1 (60 Hz) Efficiency class: IE3 Protection class: IP55 200-240 V; 50 Hz; 9.0 A/200-240 V; 60 Hz; 8.8 A 200 V; 50 Hz; 9 A (IE3 = 86.7%) 208-240 V; 60 Hz; 7.8 A (IE3 = 89.5%) 380-400 V; 50 Hz; 4.5 A/400-480 V; 60 Hz; 4.4 A 380-400 V; 50 Hz; 4.5 A (IE3 = 86.7%) 416-480 V; 60 Hz; 3.9 A (IE3 = 89.5%) Suitable for line voltages +/- 10% Suction flange: DN40KF can be used horizontally and vertically Outlet flange: DN40KF can be used horizontally and vertically Cooling: air equipment: Manual gas ballast device (on/off) Inert gas connection for the M16x1.5 gas ballast Inert gas connection for the M16x1.5 oil box oil drain and oil filler plug Box contents: user manual spare parts list 2 x centering and clamping rings Leybonol LVO 100 oil filling Recommended accessories: OF 40-65 or CF 40-65 are main flow oil filter devices that also can be attached to the pump retroactively. The Indians TRIVAC B built-in oil pump draws in the oil and pumps it through the oil filter device, only then does the purified oil reach the Lubricate the pump. This is how the oil filter device does not extend only the oil life, but also the life of the pump |
| Weight | 1 |
Please contact us to request a price quote for Leybold - 11296 / TRIVAC D65B, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
