| Manufacturer | Leuze |
|---|---|
| Part Number | FT318B.W3/4P |
| Inner Code | 746141 |
| Description | Lichttaster energetisch |
| Weight | 1 |
Please contact us to request a price quote for Leuze - FT318B.W3/4P , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Safety Relay SIL 3 IEC 61508 Performance Level (PL) e, EN ISO 13849-1 Category: 4, EN ISO 13849 STOP category 0, IEC / EN 60204-1 Response time: 10 ms Number of safety outputs (OSSD): 3 pc Safety switching output 1: relay, make Safety switching output 2: Relay closure Safety output 3: Relay closure Connection: Screw Dimensions: 22.5 mm x 99 mm x 114.1 mm Ambient operating temperature: 0 ... 55 ° C Approvals: CE, TÜV Süd, c TÜV NRTL U.S. Functions: cross circuit monitoring, restart interlock (RES), selectable, automatic Start / Restart, External Device Monitoring (EDM) Customs number / customs item no: 853710991 Weight in kg per unit / per kg weight apiece. 0.22
RELAY-EMERGCY STOP RELAY SAFETY CATEGORY : UP TO CAT 4, EN 954-1 STOP CATEGORY : STOP 0 (IEC60204-1) ENCLOSURE RATING : IP 20 SUPPY VOLTAGE : 24VAC/DC 10%/-15% CONTACT LOAD : 3A / 230VAC MAX EMPERATURE RENGE : 0-50 DERECE RESPONSE TIME : 50MS
Safety Relay Safety sequential circuit and emergency stop relay for AOPDs, emergency stop devices and safety gates according to IEC EN 60204-1, Stop Category 0 Wiring: Category 4 according to EN ISO 13849-1:2006 Safety category 4, PL e according to EN ISO 13849-1:2006 Operating voltage: 24V AC / DC + / - 20% Safety outputs (OSSD): 3 relay outputs (NO) Signal output: 1 relay output (NC) Response time: 10 ms ON delay (automatic start): 300 ms ON delay (manual start): 30 ms Status Indicators: Ub, K1, K2, Res Dimensions (H x W x D): 99 x 22.5 x 111.5 mm
SAFETY RELAY
Safety Relay SIL: 3, IEC 61508 Performance Level (PL) e, EN ISO 13849-1 Category: 4, EN ISO 13849 STOP category: 0, IEC / EN 60204-1 Response time: 10 ms Number of safety outputs (OSSD): 3 Hours Safety Relay Output 1: Relay closure Safety Relay Output 2: Relay closure Safety Relay Output 3: Relay closure Connection: Screw Dimensions: 22.5 mm x 113.6 mm x 99 mm Ambient temperature Operating: 0 ... 55 ° C Approvals: CE, UL, TUV NRTL US Functions: Automatic start / restart, Start / restart interlock (RES), selectable, Static (EDM), short circuit monitoring Customs tariff number / customs item no: 853710991 Weight in kg per piece / weight per kg apiece. 0.21
Polarized reflex sensor
Block mirror Optical Barrier
Polarized reflex sensor Maximum distance: 0.05 ... 10 m Light source: LED, red Switching frequency: 500 Hz Supply voltage: 10 ... 30 V, DC Number of digital switching outputs: 2 pcs Digital switching output 1: transistor push-pull, light switching (PNP) / dark switching (NPN) Digital switching output 2: transistor push-pull, dark switching (PNP) / light switching (NPN) Connection: Cable with connector, 200 mm, M12, metal Number of positions: 4 pcs Design Housing: cube Dimensions: 15 mm x 38.9 mm x 28.7 mm Housing material: plastic Protection: IP 67, IP 66
Retro-reflective sensor pole.
Retro-reflective sensor polarized Typical operating range limit - / - scanning distance: 18000 mm Housing: Plastic Light source: red Output: 2 x push-pull Voltage: 10-30V DC
Reflex-Lichtschranke polarisiert
reflex sensor
With mounting and cables
Unpolarized reflex sensor
Infrared Sensors
Infrared Sensors
SIZE 68 CM
ROBUST SENSOR PHOTOCELL
Sicherheits-Laserscanner
Scanner windscreen Set Caution: replacing the disc must access code software Lumiflex only be performed by trained personnel. (Calibration of the disc)
Safety Light Curtain Receiver Type 2 according to IEC / EN 61496 Classification according to IEC / EN 61508 SIL 2 receiver Safety outputs (OSSD): 2 PNP transistor outputs Profile cross-section: 30 mm x 34 mm Resolution: 40 mm Range: 0,8 - 20 m Protective field height: 900 mm Connection: M12 connector, 5-pin Power supply: 24V DC + / - 20% Protection: IP 65 Features: integrated testing, automatic Start / restart, selectable transmission channels Included in delivery: 2 bracket sets BT-360-SET 1 connecting and operating instructions (PDF file on CD-ROM)
Safety Light Curtain Transmitter Type 2 according to IEC / EN 61496 Classification according to IEC / EN 61508 SIL 2 transmitter Profile cross-section: 30 mm x 34 mm Resolution: 40 mm Range: 0,8 - 20 m Protective field height: 900 mm Connection: M12 connector, 5-pin Power supply: 24V DC + / - 20% Protection: IP 65 Included in delivery: 2 bracket sets BT-360-SET 1 connecting and operating instructions (PDF file on CD-ROM)
