Siemens (Landis Gyr) - 100020 SQM50.543A80B
Manufacturer | Siemens (Landis Gyr) |
---|---|
Part Number | 100020 SQM50.543A80B |
Inner Code | 16475 |
Description | (Actuator for gas and air valves without AGA56 ... with single-wire potentiometer 135 ohm / 90 ° Rotation: reversible Rotary u. Holding torque 15 Nm Drive shaft: No. 3, 9 mm quadr, zweisietig.. Drive shaft: interchangeable Duration (at 50Hz): 45s / 90 °, 65s / 130 ° Setting angle: up to 160 ° Limit: 2 Auxiliary contacts: 2 Voltage: AC24 V-15% / + 10% Frequency: 50 ... 60 Hz + -6% Power consumption: 20 VA Protection: IP54 Temperature range: -20 ... + 60 ° C Humidity: <95% RH Cable entry: 4 x Pg13,5 threaded 2 x Pg13,5 Unthreaded Dimensions: 180 x 132 x 133 (L x W x H in mm) Weight: 3,50kg Country of origin: Germany / Stat. W-No .: 84169000 AL: N ECCN: EAR99) |
Weight | 1 |
Please contact us to request a price quote for Siemens (Landis Gyr) - 100020 SQM50.543A80B, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
