Küenle - KTE3 132 S x 2 KT HAN FL IE3
| Manufacturer | Küenle |
|---|---|
| Part Number | KTE3 132 S x 2 KT HAN FL IE3 |
| Inner Code | 4593062 |
| Description | three-phase K motor |
| Technical specification | 7.5 kW S1 DR 400 V 13.6 AMPS IN THE B35 (300) IE3, 90.1% 50 Hz 2940/min IP 55 Insulation class: F DS: 6208 ZZ C3 NS: 6208 ZZ C3 Motor efficiency according to IE3 (IEC 60034-30) with 3 built-in temperature sensors (PTC thermistor) shaft D 38 x 80 mm long normal storage fixed bearing D-side with harting plug HAN10E outlet in the direction of the fan shroud Connector assignment (standard): 1=U1 2=V1 3=W1 4+5=free 6=W2 7=U2 8=V2 9+10=PTC |
Please contact us to request a price quote for Küenle - KTE3 132 S x 2 KT HAN FL IE3, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
