Küenle - KTE3 132 S 4 BIS
| Manufacturer | Küenle |
|---|---|
| Part Number | KTE3 132 S 4 BIS |
| Inner Code | 5018308 |
| Description | motor |
| Custom Code | 85015220 |
| Technical specification | 5.5 kW UT 80°C Dr/Y 400/690V 10.6/6.3 A 4.8 kW UT 100°C Dr/Y 400/690V 9.3/5.5 A IN B3 IE3, 89.6% 50 Hz 1470/min 50 Hz 1470/min IP 55 Insulation class: F DS: 6208 ZZ C3 NS: 6208 ZZ C3 with 3 built-in temperature sensors (cold conductor) Shaft D 38 x 80 mm long normal storage motor unventilated, N side closed, Sits in the airflow on site - required air volume 6.0 m³/min Motor without terminal box, 4 m long with cable removed Motor connection: 7 x 2.5mm² Cold conductor: 4x0.75mm² |
Please contact us to request a price quote for Küenle - KTE3 132 S 4 BIS, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
