Küenle - 040502.000138
| Manufacturer | Küenle |
|---|---|
| Part Number | 040502.000138 |
| Inner Code | 4756017 |
| Description | Three-phase motor |
| Technical specification | MEP 2.5/3000/230-400/50/1.4462 IMB14-Ø120, ASF, BG90L, Shaft E-MEP-ME-750_008-001 three-phase motor 2.5 kW, 2-pole 3000 min-1, 230/400 V ± 5%, 50 Hz, 3600 min-1, 265/460 V ± 5%, 60 Hz, Details and options: Frame size 90 IMB14 design with Ø120 flange Shaft according to drawing Wave E-MEP-ME-750_008+/-001, 1.4462 A-sided fixed bearing Protection class IP 55 Ambient temperature -15°C to +40°C Metal terminal box and fan cover Terminal box at the top Type plate with wide voltage range 60 Hz nameplate enclosed loose or stamped on a nameplate IE3 efficiency class CE, UL, CSA Paint: RAL7011 Hexagon socket at the end of the shaft Motor can be used for the following pump types: ME-VF 750/15 - 250-50 and ME-VF 750/15 - 250-60 |
Please contact us to request a price quote for Küenle - 040502.000138, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
