Küenle - 040502.000136
| Manufacturer | Küenle |
|---|---|
| Part Number | 040502.000136 |
| Inner Code | 4756027 |
| Description | Three-phase motor |
| Technical specification | MEP 1.5/3000/230-400/50/1.4462 IMB34-Ø120, ASF, BG80, shaft E-MEP-ME-750_008/-001 1.5 kW three-phase motor, 2-pole 3000 min-1, 230/400 V ± 5%, 50 Hz, 3600 min-1, 265/460 V ± 5%, 60 Hz, Details and options: Frame size 80 IMB34 design with Ø120 flange Wave based on drawing E-MEP-ME-750_008/-001 from 1.4462 A-sided fixed bearing Protection class IP 55 Ambient temperature -15°C to +40°C Metal terminal box and fan cover Terminal box seen on the wave on the right Type plate with wide voltage range 60 Hz nameplate enclosed loose or stamped on a nameplate IE3 efficiency class CE, UL, CSA Paint: RAL7011 Hexagon socket at the end of the shaft Motor can be used for the following pump types: LD/S 80 and LD/S 80-G |
Please contact us to request a price quote for Küenle - 040502.000136, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
