Kübler - ASH/ME/FM74-V/U-L200/12-1/SVK44/15/A
| Manufacturer | Kübler |
|---|---|
| Part Number | ASH/ME/FM74-V/U-L200/12-1/SVK44/15/A |
| Inner Code | 1684083 |
| Description | Magnetic float level switch |
| Technical specification | • design pressure: 0 / 0.5 bar • working pressure: 0 / 0.5 bar • density: 800 kg/m³ please check • design temperature: -10 / 80 °C • working temperature: -10 / 80 °C • ambient temperature: -10 / 80 °C electrical connection • ASH: connector in polyamide according to DIN 43650 with cable entry M16 / IP65 process connection • ME: material quality brass • FM74: process connection flange Ø 74 mm ( hole circle 60 mm / hight 5 mm / 4 x Ø 5.5 mm ) guide tube • V: material quality stainless steel 1.4404 / 1.4435 / 1.4571 ( 316L & 316Ti ) • 12: tube outside diameter Ø 12.00 mm • L [mm] / M [mm]: L = 200 mm level contact function • U: switch function change over ( SPDT ) L1 = 160 mm • switch rating: 230V / 0.5A / 40VA number / of floats • 1 / SVK44/15/A: stainless steel 1.4571 ( 316Ti ) / Ø 44 x 52 mm / inner bore Ø 15 mm • float stop: welded pin |
| Weight | 2 |
Please contact us to request a price quote for Kübler - ASH/ME/FM74-V/U-L200/12-1/SVK44/15/A , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
