Kübler - AFMS-L600-SVK-R
| Manufacturer | Kübler |
|---|---|
| Part Number | AFMS-L600-SVK-R |
| Inner Code | 1813093 |
| Description | Magnetic Float Switch Type FLS-SA |
| Technical specification | (ASC4FPP120/LK100-VS-L600/12-V44A-verstellbar) Material: Stainless steel 316Ti (DIN 1.4571) Pressure: 0.5 bar Temperature range: -10°C up to 80°C Fluid density: 1000 kg/m³ Electrical connection: Coupler plug 4 pin DIN 43650 Process connection: Flansch PP120/LK100 (Renault) Switch function 1: Closing on rising level (SPST) 555 mm Switch rating: max. AC 250V; 100VA; 1A / DC 250V; 50W; 0.5A Float: Stainless steel 316Ti V44A Number of floats: 1 pc Guide tube: OD 12 mm Insertion length (L): 600 mm Additional ordering information: with Viton O-Ring 73x3mm similar sketch KSR 4974 |
| Weight | 2.5 |
Please contact us to request a price quote for Kübler - AFMS-L600-SVK-R , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
