Kraus & Naimer - MAN.SW.3P.2POS 315 2AX NO.NC
| Manufacturer | Kraus & Naimer |
|---|---|
| Part Number | MAN.SW.3P.2POS 315 2AX NO.NC |
| Inner Code | 4216355 |
| Description | BYPASS switch |
| Technical specification | U nom. - not less than 690 V, U nominal impulse. - not less than 6 kV And nom. switching - not less than 315A, Switching property: - not less than 2000 A at 220V-240V (380V-440V) - not less than 340 A at 660V-690 V Short-term rated current (1 sec. Current) not less than 4200 A, 2-position, 3-phase, uninterrupted The length of the switch is 165 mm The diameter of the holes in the connection terminals is 12.5 mm Method of fastening on the front and back side end square - 4 holes with a diameter of 7 mm and a distance between the centers of the holes 104 mm Compliance with standards: - IEC 60947-3 - EN 60947-3 |
Please contact us to request a price quote for Kraus & Naimer - MAN.SW.3P.2POS 315 2AX NO.NC, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
