KIMO - TH210-HODI-300-R-05M

Manufacturer KIMO
Part Number TH210-HODI-300-R-05M
Inner Code 4747309
Description Temperature and humidity transmitter
Technical specification with display offset stainless steel probe Sensor length: 300 mm/diameter: 13 mm Cable length 5 m (other lengths available) (Optional sensor mounting clamps Duct mounting: BF13 or BFP-13 Wall mount: RBE-13) Humidity: 5... 95% RH Temperature: -40... +180 °C More Features: Absolute humidity, dew point, enthalpy which is also available as an analog output signal can be used. Power supply: 100-240 Vac 2 x analog outputs: 4... 20 mA or 0... 10 V 2 relay outputs/changeover contacts (3A/ 230V) Enclosure/protection class: ABS, IP 65 Weight: approx. 350 g Article number: 56-27092

Please contact us to request a price quote for KIMO - TH210-HODI-300-R-05M, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

KIMO-TH210-HODI-300-R-05M price

More products of KIMO

  • 56-20810

    Temperature probe Type: FKI-3-1000-MM (thermocouple type K) Measuring range: -40 ... + 1000 ° C Diameter: 3 mm Probe length. 1000 mm / incl miniature connector

  • 56-20823-TBJI-6-900

    Thermocouple - temperature sensor with terminal head Technical specifications: Temperature range: -40 .. + 750 ° C Design: Type J Fe-Con (JI isolated) Probe diameter: 6 mm Probes - Length: 900 mm Type: TB-JI-6-900

  • 56-21631

    Infrared thermometer, KIRAY 200 with laser pointer IR measurement range: -50 to + 850 ° C D.S. .: 30: 1 with input for thermocouple Measuring range for the supplied thermocouple: -40 ... + 400 ° C Measurement range for temperature display: -50 ... + 1370 ° C features: Adjustable emissivity: from 0.1 to 1.0 Backlight, min-max function, audible alarm (high, low) Included: external Thermocouple type K (cable sensor), Carrying case and operating instructions

  • 56-21791, LX 200

    Digital luxmeter - Class B (standard NF C 42-710) Measuring range: 0.1 ... 200 000 Lux Functions: Hold, Min / max, average, and much more ... with data storage and comprehensive evaluation Scope of supply: calibration, soft case carrying case evaluation

  • 56-22593

    KISTOCK Data Logger Type: KH-110-AO with display Data storage: 16,000 data points (2 adjustable visual alarm signals) Internal measuring ranges: Environment - Humidity: 5 ... 95% Ambient temperature: -20 ... + 70 ° C Light sensor: 0 to 10,000 Lux .... Housing with magnetic holder Protection: IP40

  • 56-24072

    Air velocity / flow transmitter Type: CTV210-BOO with display incl. non-directional flow probe for very low flow rates Probe length: 300 mm Height: 85 mm Cable length: 2 m (other lengths available) Measuring ranges: Air velocity: 0 ... up to 5 m / s Flow 0 ... 100 000 m³ / h Temperature 0 ... 50 ° C (Pt100 - Sensor 1/3 DIN) outputs: 2 analogue outputs 4-20 mA or 0-10 V Supply voltage: 24 V AC / DC ABS housing, IP 65

  • AMI 300 PRO

    with large color display - recording of measurements up to 12,000 measuring points

  • AQ 100 S

    Hand device for CO2 measurements Type: AQ 100 S Measuring range: 0 ... 5000 ppm . Temp Range: -20 ... +80 ° C

  • CE 300

    [Sleeve for handheld instrument of the 300 series of shockproof material with magnet, shoulder strap and practical stand Item No .: 56-17053]

  • CP 202-BO obsolete,replaced by CP212-BO

    differential pressure transmitter, IP 65, 0 +/- 100 mmCE, 4-20 mA and 0-10 V 2 outputs,RS 232, 6A/230 VA.C. SQR debi, LCC-300

  • CP113-AO

    Differential pressure transmitter

  • CP212-BO,56-24029

    Differential pressure transmitter with display Pressure measuring range: -1000 / +1000 Pa (Optional is also the possibility of a Air velocity and flow function) Temperature input: Pt100 of -100..bis + 400 ° C Auto Zero: Through key or atom. with solenoid valve Accuracy: +/- 0.5% of the measured value Power supply: 24V AC / DC 2 analogue outputs 0-10 V or 4-20 mA / 0-20 mA PC interface: USB Mini DIN Housing: ABS, IP 65

  • CP50

    The Differential Pressure Transmitters

  • CTV110-VNA300/OHNE DISPLAY

    Lufgeschwindigkeit and temperature transmitter

  • CTV110-VOA300/MIT DISPLAY

    Air velocity and temperature transmitter

  • FG100S

    Gas detector for the detection of gas leaks Type: FG 100 S with Backlight

  • HD 100 E

    Thermo-/ Hygrometer

  • HD 100 S

    Temperature / Humidity - handheld instrument

  • HD 100 S

    Temperature / Humidity - handheld instrument Type: HD 100 S (Thermo-Hygrometer) Measuring range: Relative humidity: 5 ... 95% RH, dew point: -40 ... + 70 ° C td Temperature: -20 ... + 70 ° C Units Switchable, Hold, Min-Max. Adjustable backlighting Incl. - Hygrosonde Ø 13 mm, - Transport case - Calibration Certificate No .: 56-16426 Customs Tariff No .: 9025 9090

  • HD100E

    Thermo-/ Hygrometer

  • HD-100S

    Temperature / Humidity - handheld instrument Type: HD 100 S (thermo-hygrometer) Measuring range: Relative humidity: 5 ... 95% RH, Dew Point: -40 ... + 70 ° C td Temperature: -20 ... + 70 ° C Units Switchable, Hold, Min-Max. Adjustable backlighting Delivery incl. - Hygrosonde Ø 13 mm, - Transport case - Calibration Certificate Item No .: 56-16426 Tariff No .: 9025 9090

  • KIGAZ 300 PRO

    Flue gas analyzer

  • LCC- S, (56-24106)

    Konfigurations-Software für Transmitter der 110 / 210 / 310 Serie

  • LGV 1000 HC2

    ifferenzdruck-Schalter

  • LV 110 S

    Vane Thermo-Anemometer / handheld instrument Measuring range: Air Speed: 0.25 ... to 35 m / s flow rate: 0 .... to 99999 m³ / h Temperature: -20 to +80 ° C .... Delivery consisting of: - vane Ø 100 mm - Transport case - Calibration Certificate No .: 56-16421 Customs Tariff No .: 9025 8091

  • MP 100 S

    Mikromanometer

  • MP 101 S

    (Measuring units available in: Pa, mmH2O, INWG, DaPa Measuring range: 0 ... + / - 1000 mm H2O (10 kPa) Pressure resistance: 700 mbar Delivery consisting of: silicone tubing (2 x 1 m) Transport case Calibration Certificate and Item No .: 56-16416 Tariff No .: 9025 8040)

  • MP 200 M

    Precision Thermo Micromanometer

  • SQR/3 (56-24105)

    Flow function
