KIMO - CTV210-HOS-R (56-25664)

Manufacturer KIMO
Part Number CTV210-HOS-R (56-25664)
Inner Code 4281878
Description Volumenstrom-Transmitter
Custom Code 90262038
Technical specification with display Includes remote stainless steel hot-wire probe probe length: 300 mm Probe diameter: 8 mm Cable length: 2m (other lengths available) Working and measuring ranges: Air speed: 0... 30 m/s (freely adjustable) Volumetric flow 0... 100,000 m³/h Temperature 0... 50°C (Pt100 - sensor 1/3 DIN) Outputs: - 2 analog outputs: 4-20 mA or 0-10 V - 2 relays (changeover contact 3A/230V) Power supply: 110/230 V AC ABS housing, IP 65 Customs tariff No: 9026 2038, Country of origin: France

Please contact us to request a price quote for KIMO - CTV210-HOS-R (56-25664), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

KIMO-CTV210-HOS-R (56-25664) price
