KIESEL - 54649
| Manufacturer | KIESEL |
|---|---|
| Part Number | 54649 |
| Inner Code | 4876237 |
| Description | progressing cavity pump |
| Custom Code | 84136080 |
| Technical specification | Gravel eccentric screw pump SP 06/1 MF 05 SP06/MF/1/B/A/KS/03/F/4.0/700/2/FU/304L/ single-stage block design Placement: horizontal Place of installation: in the building Ambient temperature: approx. 20°C assumed Humidity: up to 50% Operating mode: continuous operation up to 8 h Materials and design: Housing: stainless steel, 1.4301 pin. Rotor: stainless steel 1.4301 polished, hollow, low vibration Rotating parts: stainless steel, wst. 1.4301, polished Stator: NBR (FDA compliant), max. solids diameter 12 mm Joints: gimbal Joint sealing: NBR Shaft sealing: single-acting carbon/ceramic sliding ring independent of the direction of rotation, drip-free Input side: DN 65 DIN11851 thread Output side: DN 65 DIN11851 thread Construction: Wst. 1.4301 chrome-nickel steel chassis Accessories: spring-loaded bypass Color: PEBBLE blue Pumping medium: wine, must, yeast, juice, shredded grape mash Temperature: max. 60 °C Suction height: max. 5 m Ws Pressure height: max. 6 bar Flow rate: approx. 2400-16000 l/h adjustable Drive: spur gear motor with attached frequency converter Power: 4.0 kW Speed: 700 rpm Voltage: 400 V Frequency: 50 Hz Design: B5 Protection class: IP55 Protection class: Iso F Switch: left/ off/ right, potentiometer with 5m cable and 16A plug |
Please contact us to request a price quote for KIESEL - 54649, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
