KIESEL - 65488 Eccentric screw pump
| Manufacturer | KIESEL |
|---|---|
| Part Number | 65488 Eccentric screw pump |
| Inner Code | 4677285 |
| Description | eccentric screw pump |
| Technical specification | Eccentric screw pump SP 45/1 MF 02 SP45/M/1/B/A/B/03/F/0.88+1.60/840+1680/P/304/ single-stage block design Materials and design: Housing: chrome-nickel steel Wst. 1.4301 Rotor: chromium-nickel steel Wst. 1.4301 Rotating parts: chromium-nickel steel grade 1.4301 Stator: NBR Joints: bolt joints Joint sealing: NBR shaft seal: single-acting mechanical seal, Regardless of direction of rotation, charcoal/ceramic Input side: DN 32 DIN 11851 thread Outlet side: DN 32 DIN 11851 thread Construction: Wst. 1.4301 chassis Finish: PEBBLE blue Performance figures: Conveying medium: wine, juice Temperature: max. 60 °C Suction height: max. 5 m Ws Pressure height: max. 6 bar Flow rate: approx. 2,200/4,200 l/h Pump shaft speed: max. 1,700 rpm Power requirement on the pump shaft: max. 1.6 kW Drive: pole-shifting three-phase motor Power: 0.88/1.60 kW Speed: 840/1680 rpm Voltage: 230 V Frequency: 60 Hz Type: B5 Protection class: IP54 Protection class: ISO F Switch: pole switch |
Please contact us to request a price quote for KIESEL - 65488 Eccentric screw pump, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
