Kidde Fenwal - FXT26S28105-XX
| Manufacturer | Kidde Fenwal |
|---|---|
| Part Number | FXT26S28105-XX |
| Inner Code | 4873653 |
| Technical specification | Thermal sensor, model FENWAL DAF 28021-005 (double thread) in Atex design: These are temperature sensors (no electronics on board) that use the "Heat rate compensated" principle for the detection of a sudden or gradual rise in temperature - Alarm temperature: (xx)* 60°C / 71°C / 88°C / 98°C / 107°C / 135°C / 163°C / 182°C / 232°C / 260°C / 315°C / 385°C - Alarm contact: Normally open, closes when tripped - Sensor body: Stainless steel - Junction box connection: Stainless steel - Sensor has a double MA-MA nipple with ½" NPT thread - Junction box: Aluminium - Box inputs: No. 2 ¾" NPT - The sensor alone is certified: UL, FM The sensor/box assembly is Atex certified CE 2460 - II 2 GD Ex db IIC T6/T5 Gb - Ex tb IIIC T85/100°C Db IP66 IECEx / UKTYPE: UKCA 8501 - II 2 GD Ex db IIC T6/T5 Gb - Ex tb IIIC T85/100°C Db IP66 INERIS 03ATEX0119X / IECEx INE 18.0023/ UKTYPE CML 21UKEX1617X The sensor is supplied complete with aluminium connection box, terminals and box fixing bracket |
Please contact us to request a price quote for Kidde Fenwal - FXT26S28105-XX, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
