Tsubaki Kabelschlepp - Mono 0345.050.065.075-4554

Manufacturer Tsubaki Kabelschlepp
Part Number Mono 0345.050.065.075-4554
Inner Code 4972115
Technical specification Tsubaki Kabelschlepp energy chain - product description energy chain Chain series... BASIC-LINE - 0345 Chain name... 0345.050.065.075-4554 Material... plastic Chain length Lk... 4,554.0 mm Pitch t... 34.5 mm Number of links n... 132 [pcs] Internal width Bi... 65.0 mm Outer width Bk... 78.0 mm Inner height Hi... 20.0 mm Chain link height hG... 28.0 mm Radius of curvature KR... 75.0 mm Bridge version... 050 (cover in outer radius, bridge in inner radius can be opened) Bridge layout... full Number of bridges nst... 132 [pcs] Bridge system/interior layout Interior layout... no divider system connection elements Variant (fixed point/driver).. FA/MA Fixed point connection - detailed information Connection variant... connection angle (integrated strain relief) Connection length l1... 62.0 mm ... Integrated strain relief Driver connection - detailed information Connection variant... connection angle (integrated strain relief) Connection length l1... 62.0 mm ... Integrated strain relief Customer material number: DISCONTINUED MODEL

Please contact us to request a price quote for Tsubaki Kabelschlepp - Mono 0345.050.065.075-4554, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Tsubaki Kabelschlepp-Mono 0345.050.065.075-4554 price
