Jumo - 902190/20-386-1001 complete code 902190/20-386-1001-1-6-190-03-4000/000
| Manufacturer | Jumo |
|---|---|
| Part Number | 902190/20-386-1001 complete code 902190/20-386-1001-1-6-190-03-4000/000 |
| Inner Code | 4175853 |
| Description | THERMOMETER |
| Technical specification | Push-in RTD temperature probe with bayonet connection Data sheet: 902190 902190/20-386-1001-1-6-190-03-4000/000 Basic type : Push-in resistance thermometer, protect.tube in stainless st., Mat.Ref.1.4571, measuring tip (120°)ceramic, bayonet lock Operating temp. : -50..+260°C/PTFE Measuring insert : 1x Pt100 in 3-wire circuit Tolerance class : Class B Diameter prot. tube : 6mm Insertion length : 190,0 mm Connecting cable end: Stripped cable ends Connect.line length : 4000 mm Protection tube : Protection tube locked (standard) Diam.protection tube: 0,00 mm Protect. tube length: 0,0 mm Tube surface finish : Stripped Company logo : JUMO |
Please contact us to request a price quote for Jumo - 902190/20-386-1001 complete code 902190/20-386-1001-1-6-190-03-4000/000, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
