Itron - H1235 / WP Woltex DN 50 Q3:40 PN 16
| Manufacturer | Itron |
|---|---|
| Part Number | H1235 / WP Woltex DN 50 Q3:40 PN 16 |
| Inner Code | 4721671 |
| Description | Horizontal Woltmann counter |
| Technical specification | Bld.200 mm Nominal flow rate: Q 3:40 Q 1:0 .63 m³/h Start-up: 0.19 m³/h Qmax: 50m³/h short-term max. load: 90 cbm/h max. pressure loss at Qn: 0.12 bar Max. operating temperature: +30°C Pressure level: PN 10/PN 16 Overall length: 200 mm Flange: 4-hole Weight: 11.4 kg Counter: 6/2 Ratio: R100 MID approval no. LNE-23696-2 Impulse generator: Standard preparation with CYBLE system for retrospective Adapting the pulse takers FS-C1 to FS-C4 or wireless module CYBLE RF. No: - incl. Fixed fee for conformity assessment- |
Please contact us to request a price quote for Itron - H1235 / WP Woltex DN 50 Q3:40 PN 16, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
