Itron - TZ/G1600 DN 200
| Manufacturer | Itron |
|---|---|
| Part Number | TZ/G1600 DN 200 |
| Inner Code | 4799075 |
| Description | Turbine Meter |
| Technical specification | Fluxi 2000 Nominal size: DN 200 Pressure rating: PN50 Connection: flange according to ANSI300 Installation length: 600 mm Material: steel Gas type: according to DVGW worksheet G260 Reading direction: front reading Flow direction: freely selectable** prepared for 2 thermowells (**when equipped with immersion sleeves, flow direction please specify) Measurement range: 1:20 (max. possible measurement range 1:30 (ND) or 1:50 (HD) available at an additional cost) Pulse generator: 2x NF pulse generator + anti- Manipulation contact Pulse value: 10 cbm/pulse Plug: Binder male 2x Ermeto EO 6S PR socket Type of lubrication: permanently lubricated (oil pump available at an additional cost) Operating temperature: -25°C to +55°C (after MID) Coating: water-based paint similar to RAL 7035 PTB approval no. DE-10-MI002-PTB001 Revision number: 2 MID approved |
Please contact us to request a price quote for Itron - TZ/G1600 DN 200, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
