InterApp - D10200.23-2KR.41.2AR.N
| Manufacturer | InterApp |
|---|---|
| Part Number | D10200.23-2KR.41.2AR.N |
| Inner Code | 4999397 |
| Description | valve with pneumatic actuator |
| Technical specification | 8230200000000406 D10200.23-2KR.41.2AR.N 2 pcs BUTTERFLY VALVE DESPONIA, WAFER, DN200 10bar, ANSI 150, AS2129D, AS2129E, C207D, JIS 16K, PN10, PN16, PN25, PN6, body EN-GJS-400-15 epoxy 200μm, shaft 1.4021, disc EN-GJS-400-15 Rilsan 250μm, liner nitrile (NBR) IA450S08.F10-F1222 A450S08.F10-F1222 2 pcs PNEUMATIC ACTUATOR, IA-MOTION, SINGLE ACTING ISO F10-F12, square 22mm, O-ring NBR, LT=-40°C/+80°C MP.F0717.F1222-GALV MP.F0717.F1222-GALV MOUNTING SET BRACKET AND COUPLING Mounting valve ISO F07, square 17 mm ISO F12 Square 22mm Mounting Actuator Galvanised steel Fail position: Normally Open, Actuator mounting: Parallel to pipe (default), severe condition: Yes, Supply Pressure: 6.0, Additional Torque Safety factor: 0.0 171X0000012 NELES-ND7103HN+MB.22SS 2 pcs NELES POSITIONER NELES-ND7103HNT+MB.22SS Digital 4-20mA (350 nL/min @ 6 bar) ND7100 - standard IP66/ NEMA 4X enclosure, mounting face according to VDI/VDE 3845, M20x1.5 conduit entry Medium capacity spool valve Stroke volume of actuator 1-3 dm3 Pneum. Connections G1/4" 4-20 mA, HART communication. Will be delivered as HART 6, can be changed to HART 7 from LUI. Supply voltage 30 VDC. Load voltage up to 9.7 VDC at 20 mA corresponding to 485 Ω (maximum voltage drop) No approvals for hazardous areas. M20x1.5 conduit entry Temperature range -40°C... +85°C/-40... +185°F With stainless steel height mounting bracket internal 2-wire (passive) position 2 pcs Transmitter. Analog position feedback signal, output 4-20 mA, supply voltage 12 - 30 VDC, external load Resistance 0 — 780 Ω, Available for ND71_H_T TUBE.SS316.8MM. TUBE.SS316.8MM. (1 METER) 4 pcs Stainless Steel (AISI 316) Rigid Tubing, diameter 8 mm. Tubing external diameter 8 mm x 1 mm in AISI 316, Supplier reference: TG816L RAC.STRAIGHT.2 RAC.STRAIGHT.SS316-M.G1/4-TINOX8 4 pcs STRAIGHT FITTING AISI316, male 1/4" G, to tube SS316 8mm. RAC.ELBOW.14 RAC.ELBOW.SS316-M.G1/4-TINOX8 6 pcs Elbow fitting AISI316, male 1/4" G, to tube SS316 8mm. 970408005100008 PSS 14 S 4 pcs SILENCER Silencer G 1/4”, single chamber principle, Damping AISI 316L, Nipple AISI 303 B82G-2GK-AD3-RFG B82G-2GK-AD3-RFG 2 pcs FILTER REGULATOR 1/4" filter regulator, 0.3 - 4 bar, body steel, Automatic Drain with Gauge |
Please contact us to request a price quote for InterApp - D10200.23-2KR.41.2AR.N, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
