Ingun - GKS-313 306 300 A 1502 M
| Manufacturer | Ingun |
|---|---|
| Part Number | GKS-313 306 300 A 1502 M |
| Inner Code | 5044073 |
| Technical specification | general data Product group: Screw contact pins Sub-product group: Screw-in GKS Series: GKS-313 M screw-in Pitch: 4.5 mm Contacting of: pin, post, flat contact Magnetic: yes Installation type: screw-in Quick change system: yes Installation height adjustable: no Anti-twist protection: no Screw-in torque: 10 - 20 cNm Suitable contact sleeve: KS-313 M Min. temperature: - 40 °C Max. temperature: + 80 °C RoHS compliant: RoHS-3; 6c Electrical data Current capacity/nominal current: 5 A Resistance (Ri) typical: < 30 mOhm Mechanical data Overall length: 57.3 mm Pin case diameter: 2.65 mm Maximum stroke: 14.3 mm Spring preload: 0.21 N E-size/Collar size: 02 Spring force during working stroke: 1.5 N Working stroke: 12 mm Head shape data Head shape: 06 waffle (riffle) Head diameter: 3 mm Head shape surface: A gold Head shape material: 3 CuBe |
Please contact us to request a price quote for Ingun - GKS-313 306 300 A 1502 M, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
