Indexator - XR300 LS
| Manufacturer | Indexator |
|---|---|
| Part Number | XR300 LS |
| Inner Code | 4251518 |
| Technical specification | ⦁ More compact, powerful and optimally stored Rotator with slewing ring bearings ⦁ For extreme areas of application with particularly high conditions ⦁ Extremely high torques ⦁ Suitable for large dynamic loads in areas Forestry, timber handling, recycling, materials and Scrap handling ⦁ 30,000 kg max.static load, 9,000 kg max. dynamic load, 7,000 kg max radial load ⦁ Torque of 3,000 Nm at 250 bar ⦁ Oil requirement 28 l / min ⦁ Weight 77 kg ⦁ Top flange mount with threaded holes (Bolt circle 12xM20-210 mm) ⦁ Mounting below, bolt circle diameter 270 mm (8x17-270 mm) ⦁ Hydraulic connections on top 2 x 3/4 "+ 2 x 1/2" ⦁ Hydraulic connections below 2 x 3/4 " |
Please contact us to request a price quote for Indexator - XR300 LS, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
