Indexator - 8000509
| Manufacturer | Indexator |
|---|---|
| Part Number | 8000509 |
| Inner Code | 3809484 |
| Description | Hydromotors |
| Technical specification | ⦁ Especially strong and stable rotators for demanding material handling ⦁ Suitable for excavators, large cranes and skidder ⦁ Same principle as IR 10 ⦁ Especially for larger attachments with high requisitions ⦁ Modular construction with few moving parts for high reliability ⦁ Available in various versions, including mechanical rotator without motor ⦁ Variant for direct connection of up to five gripping cylinders without distribution block ⦁ Good storage for forces in various record load directions ⦁ 45,000 kg max. static load, 15,000 kg max. dynamic load ⦁ torque of 4,100 Nm at 250 bar ⦁ oil requirement 35 l/min ⦁ Weight 146 kg ⦁ Top flange attachment with threaded holes (bolt circle 6xM20-220 mm) ⦁ Bottom hole circle 340 mm diameter (10x26-340 mm) ⦁ Top hydraulic connections 2 x G 1" + 2 x G 1/2" ⦁ Hydraulic connections below 3 x SAE 3000 DN 25 /SAE 6000 DN 32/G1 |
| Weight | 145 |
Please contact us to request a price quote for Indexator - 8000509, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
