Indexator - P/N: 8000309, Type: IR10 M20
| Manufacturer | Indexator |
|---|---|
| Part Number | P/N: 8000309, Type: IR10 M20 |
| Inner Code | 590596 |
| Description | Grapple rotator |
| Technical specification | Suitable for excavators, large cranes and skidders ⦁ Rotary execution function with low pressure drop ⦁ Available in different versions ⦁ Variant for direct connection of up to five Gripping cylinders without distributor block ⦁ Absorption of forces from different load directions ⦁ 25,000 kg max. static load, 7,000 kg max. dynamic load ⦁ Torque of 2,100 Nm at 250 bar ⦁ Oil requirement 25 l/min ⦁ Weight 84.6 kg ⦁ Top flange mount with holes and thread (bolt circle 6xM20-200 mm) ⦁ Bottom mounting bolt circle 275 mm diameter (10 x 17-275 mm) ⦁ Hydraulic connections at the top 2 x G 3/4 “+ 2 x G 1/2" ⦁ Hydraulic connections at the bottom 2 x SAE 3000+ 3 x G 3/4" |
| Weight | 1 |
Please contact us to request a price quote for Indexator - P/N: 8000309, Type: IR10 M20, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
