Indexator - IR 20-5 M24
| Manufacturer | Indexator |
|---|---|
| Part Number | IR 20-5 M24 |
| Inner Code | 4363344 |
| Description | ROTATOR |
| Technical specification | 8000486 ⦁ Particularly strong and stable rotators for demanding material handling ⦁ Suitable for excavators, large cranes and skidder ⦁ Same principle as IR 10 ⦁ Especially for larger attachments with high demands ⦁ Module construction with few moving parts for high reliability ⦁ Available in various versions, including mechanical rotator without motor ⦁ Variant for direct connection of up to five gripping cylinders without distribution block ⦁ Good storage to absorb forces in different load directions ⦁ 45,000 kg max. static load, 15,000 kg max. dynamic load ⦁ torque of 4,100 Nm at 250 bar ⦁ oil requirement 35 l/min ⦁ Top flange with threaded holes (bolt circle 6xM24-230 mm) ⦁ Bottom hole circle 340 mm diameter (10x26-340 mm) ⦁ Top hydraulic connections 2 x G 1" + 2 x G 1/2" ⦁ Hydraulic connections below 16 x G 1/2" |
Please contact us to request a price quote for Indexator - IR 20-5 M24, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
