Indexator - IR 12
| Manufacturer | Indexator |
|---|---|
| Part Number | IR 12 |
| Inner Code | 4744698 |
| Description | Rotator |
| Technical specification | Max. Operating pressure (bar): 250 Suitability for heavy duty use: Yes Typical application: Clamshell grapple, Orange peel grapple, scrap grabber part / component: Built-in Rotator model: Indexator IR Rotator size: IR12 execution: IR12 Type of rotator: Built-in Rotator Static load max. (kg): 25,000 Dynamic load max. (kg): 7000 Torque (Nm): 2900 Design connection at the top: flange with bore and threads Dimension connection above: Bolt circle 6xM20-200 mm Hydraulic inlet connections at the top: 2 x 1 1/16"-12 UNF + 2 x Version connection below: flange Dimension connection below: Bolt circle 12x17-275 mm Hydraulic inlet connections at the bottom: 5 x 1 1/16"-12 UNF |
Please contact us to request a price quote for Indexator - IR 12, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
