Indexator - 8000307 / IR 10H M16
| Manufacturer | Indexator |
|---|---|
| Part Number | 8000307 / IR 10H M16 |
| Inner Code | 4683318 |
| Description | Rotator |
| Technical specification | Max. Operating pressure (bar): 250 Suitability for heavy duty use: Yes Typical application: Clamshell grapple, grapple for tong tractor, Orange peel grapple, scrap grabber part / component: Built-in Rotator model: Indexator IR Rotator size: IR10 execution: IR10-H-M16 Type of rotator: Built-in Rotator Static load max. (kg): 25,000 Dynamic load max. (kg): 7000 Torque (Nm): 2100 Design connection at the top: flange with bore and threads Dimension connection above: Bolt circle 6xM16-180 mm Hydraulic inlet connections at the top: 4 x G 1/2" + 2 x G 3/4". Version connection below: flange Dimension connection below: Bolt circle 10x17-275 mm Hydraulic inlet connections at the bottom: 2 x SAE 3000 + 3 x G 3/4 Suitable for machine type: Excavator, Handling machine Suitable for machine manufacturers: Atlas, Baljer&Zembrod, CAT, Fox, hitachi, Kobelco, komatsu, Liebherr, multi docker, Sennebogen, TEREX Suitable for crane manufacturers: Atlas, Baljer&Zembrod, CAT, Fox, hitachi, Kobelco, komatsu, Liebherr, multi docker, Sennebogen, TEREX |
Please contact us to request a price quote for Indexator - 8000307 / IR 10H M16, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
