Indexator - 5212047 / GV 12-2-A
| Manufacturer | Indexator |
|---|---|
| Part Number | 5212047 / GV 12-2-A |
| Inner Code | 4062302 |
| Description | Rotator |
| Technical specification | Powerful hydraulic rotator Very durable construction - vane cell rotator with a unique finish 10,000 kg max static load, 5,000 kg max dynamic load High torque of 2200 Nm at 250 bar Low oil consumption 25 l/min Favorable power-to-weight ratio 2 tabs with 80.5 mm tab spacing and 35 mm bore for bolts at the top Bottom mount 6-hole flange 173 mm diameter (6x17-173 mm) Hydraulic connections at the top 4 x BSP 1/2" IT, 2 hose inlets each left and right with hose protection bar Hydraulic connections below 2 x BSP 1/2" IG in the shaft axially downwards |
Please contact us to request a price quote for Indexator - 5212047 / GV 12-2-A, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
