Indexator - 5212048 / GV 12-2
| Manufacturer | Indexator |
|---|---|
| Part Number | 5212048 / GV 12-2 |
| Inner Code | 4185876 |
| Description | Rotator |
| Technical specification | size: GV12 execution: GV12-2 Type of rotator: Rotator for grapple Static load max. (kg): 10,000 Dynamic load max. (kg): 5000 Torque (Nm): 2200 Design connection at the top: Clevis with 2 tabs Dimension connection above: tab spacing 80.5 mm with 35 mm bore Hydraulic inlet connections at the top: 4 x G 1/2 Version connection below: flange Dimension connection below: Flange flange Hydraulic inlet connections at the bottom: 2 x G 1/2" in the shaft axially downwards and the same channel on the side (radial) in the flange 2 x G 1/2". |
Please contact us to request a price quote for Indexator - 5212048 / GV 12-2, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
