Indexator - Type IR 10H M20 Nr. 8000309
| Manufacturer | Indexator |
|---|---|
| Part Number | Type IR 10H M20 Nr. 8000309 |
| Inner Code | 3827100 |
| Description | Rotator |
| Custom Code | 84122981 |
| Technical specification | Particularly strong and stable rotators for demanding material handling ⦁ Suitable for excavators, large cranes and skidders ⦁ Rotation function with low pressure loss ⦁ Available in various designs ⦁ Variant for direct connection of up to five Gripping cylinders without distributor block ⦁ Absorption of forces from various load directions ⦁ 25,000 kg max. static load, 7,000 kg max. dynamic load ⦁ Torque of 2,100 Nm at 250 bar ⦁ Oil requirement 25 l/min ⦁ Weight 84.6 kg ⦁ Upper flange mount with holes and thread (bolt circle 6xM20-200 mm) ⦁ Picture below bolt circle 275 mm diameter (10 x 17-275 mm) ⦁ Hydraulic connections at the top 2 x G 3/4" + 2 x G 1/2" ⦁ Hydraulic connections at the bottom 2 x SAE 3000 + 3 x G 3/4" |
| Weight | 84.6 |
Please contact us to request a price quote for Indexator - Type IR 10H M20 Nr. 8000309, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
