Indexator - 5212349
| Manufacturer | Indexator |
|---|---|
| Part Number | 5212349 |
| Inner Code | 5019789 |
| Description | Gripper rotator |
| Technical specification | Max. operating pressure (bar): 250 Typical application: Construction industry, firewood, forestry, gardening and landscaping, track construction, timber industry, recycling Part/component: rotator for gripper Model: Indexator GV Rotator size: GV12 Model: GV12-LS Rotator type: rotator for gripper Static load max. (kg): 10000 Dynamic load max. (kg): 5000 Torque (Nm): 2200 Top connection design: fork head with 2 lugs Connection dimensions at the top: lug spacing 80.5 mm with 35 mm hole Hydraulic input connections at the top: 4 x G 1/2 Bottom connection design: flange Bottom connection dimension: flange 6x17-173 mm Hydraulic input connections at the bottom: 2 x G 1/2" in the shaft axially downwards and the same channel laterally (radially) in the flange 2 x G 1/2 Suitable for machine type: forestry tractor, timber transport truck, tractor |
Please contact us to request a price quote for Indexator - 5212349, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
