Indexator - 5002634 / GV 4/30-I
| Manufacturer | Indexator |
|---|---|
| Part Number | 5002634 / GV 4/30-I |
| Inner Code | 4641364 |
| Technical specification | Powerful hydraulic rotator Very durable construction - vane rotator with unique workmanship 4,500 kg max static load, 2,500 kg max dynamic load torque of 1150 Nm at 250 bar low oil consumption 12 l/min top mount with 75 mm and 30 mm bore for bolts Bottom intake 4-hole flange 173 mm diameter (4x17-173 mm) Hydraulic connections on top 4 x BSP 3/8" female thread all on one side, one hose protection bar Hydraulic connections at the bottom 2 x BSP 3/8" female thread in the shaft axially downwards and the same channel laterally (radially) in the flange 2 x BSP 3/8" closed with covers |
Please contact us to request a price quote for Indexator - 5002634 / GV 4/30-I, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
