Ifm - KQ5010
| Manufacturer | Ifm |
|---|---|
| Part Number | KQ5010 |
| Inner Code | 1119812 |
| Description | Capacitive sensor |
| Technical specification | KQ-3040NAPKG/0,04M/AS, Origin: DEUTSCHLAND, Custom Tariff No. 85365019, Weight in KG: 0,067 Product characteristics Electrical design PNP Output function normally closed Sensing range [mm] 8; (preset: 4,0 mm (± 0,2 mm)) Housing rectangular Dimensions [mm] 20 x 7 x 48 Electrical data Operating voltage [V] 10...36 DC; (UL - Class 2 source required) Current consumption [mA] < 17 Protection class III Reverse polarity protection yes Outputs Electrical design PNP Output function normally closed Max. voltage drop switching output DC [V] 2.5 Permanent current rating of switching output DC [mA] 100 Switching frequency DC [Hz] 10 Short-circuit proof yes Overload protection yes Monitoring range Sensing range [mm] 8; (preset: 4,0 mm (± 0,2 mm)) Sensing range adjustable yes Factory setting sensing range [mm] 4 Accuracy / deviations Correction factor glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2 Hysteresis [% of Sr] 1...15 Switch-point drift [% of Sr] -20...20 Operating conditions Ambient temperature [°C] -25...80 Protection IP 65; IP 67 |
| Weight | 1 |
