Ifm - II5956
| Manufacturer | Ifm |
|---|---|
| Part Number | II5956 |
| Inner Code | 1119737 |
| Description | Inductive sensor. |
| Technical specification | IIK3012BBPKG/1,03M/PH/packard, Origin: DEUTSCHLAND, Custom Tariff No. 85365019, Weight in KG: 0,147 Electrical design PNP Output function normally open Sensing range [mm] 12 Housing Threaded type Dimensions [mm] M30 x 1.5 / L = 58 Electrical data Operating voltage [V]: 10...36 DC Current consumption [mA]: < 15 Protection class II Reverse polarity protection: yes Outputs Electrical design PNP Output function normally open Max. voltage drop switching output DC [V] 2.5 Permanent current rating of switching output DC [mA] 250 Switching frequency DC [Hz] 100 Short-circuit protection yes Type of short-circuit protection yes (non-latching) Overload protection: yes |
| Weight | 1 |
Please contact us to request a price quote for Ifm - II5956, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
