Ifm - IG6592
| Manufacturer | Ifm |
|---|---|
| Part Number | IG6592 |
| Inner Code | 1119708 |
| Description | Inductive Sensor. |
| Technical specification | IGA4008BCPKG/US-100-DPA, Origin: DEUTSCHLAND, Custom Tariff No. 85365019, Weight in KG: 0,075 Product characteristics Electrical design PNP Output function complementary Sensing range [mm] 8 Housing Threaded type Dimensions [mm] M18 x 1 / L = 89 Electrical data Operating voltage [V] 10...36 DC Current consumption [mA] 15; (24 V) Protection class II Reverse polarity protection yes Outputs Electrical design PNP Output function complementary Max. voltage drop switching output DC [V] 2.5 Max. leakage current [mA] 0.5 Permanent current rating of switching output DC [mA] 100 Switching frequency DC [Hz] 500 Short-circuit protection yes Type of short-circuit protection yes (non-latching) Overload protection yes Monitoring range Sensing range [mm] 8 Operating distance [mm] 0...6.48 Accuracy / deviations Correction factor steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2 Hysteresis [% of Sr] 1...15 Operating conditions Ambient temperature [°C] -40...80 Protection IP 67; IP 69K |
| Weight | 1 |
Please contact us to request a price quote for Ifm - IG6592, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
