Ifm - MS5013
| Manufacturer | Ifm |
|---|---|
| Part Number | MS5013 |
| Inner Code | 1119879 |
| Description | Magnetic Sensor |
| Custom Code | 85365019 |
| Technical specification | MS-3060-APKG/AS Product characteristics Electrical design PNP Output function normally closed Sensing range [mm] 60; (referred to magnet M 4.0) Housing rectangular Dimensions [mm] 28 x 10 x 16 Application Special feature Gold-plated contacts Electrical data Operating voltage [V] 10...30 DC Current consumption [mA] < 10 Protection class III Reverse polarity protection yes Outputs Electrical design PNP Output function normally closed Max. voltage drop switching output DC [V] 2.5 Permanent current rating of switching output DC [mA] 200 Switching frequency DC [Hz] 5000 Short-circuit protection yes Overload protection yes Detection zone Sensing range [mm] 60; (referred to magnet M 4.0) Accuracy / deviations Hysteresis [% of Sr] 1...10 Operating conditions Ambient temperature [°C] -25...75 Protection IP 67 |
| Weight | 1 |
Please contact us to request a price quote for Ifm - MS5013, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
