Ifm - IF5948
| Manufacturer | Ifm |
|---|---|
| Part Number | IF5948 |
| Inner Code | 1119647 |
| Description | Inductive sensor |
| Custom Code | 85365019 |
| Technical specification | IFK4004BCPKG/US-104-DPA Electrical data Operating voltage [V] 10...30 DC Current consumption [mA] < 15 Protection class II Reverse polarity protection yes Outputs Electrical design PNP Output function complementary Max. voltage drop switching output DC [V] 2.5 Permanent current rating of switching output DC [mA] 200 Switching frequency DC [Hz] 700 Short-circuit protection yes Overload protection yes Detection zone Sensing range [mm] 4 Real sensing range Sr [mm] 4 ± 10 % Operating distance [mm] 0...3.24 Increased sensing range yes Accuracy / deviations Correction factor steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3 Hysteresis [% of Sr] 3...15 Switch point drift [% of Sr] -10...10 Operating conditions Ambient temperature [°C] -20...80 Protection IP 67 |
| Weight | 1 |
Please contact us to request a price quote for Ifm - IF5948, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
