Honsberg - VR-010GR007-480598
| Manufacturer | Honsberg |
|---|---|
| Part Number | VR-010GR007-480598 |
| Inner Code | 4839246 |
| Description | flow monitor |
| Custom Code | 85365080 |
| Technical specification | Nominal size: DN 10 Connection: internal thread G Case: gunmetal Pressure resistance: PN 25 Media temperature: -20... +120 °C Switching range/special quantity: 3... 8 l/min on/2... 7 l/min off Switch head: metal Adjustment: longitudinal groove El. Connection: Tuchel plug, 4-pin El. Contact: reed switch Contact capacity: 250 V AC 1.5 A 50 VA Connection diagram: Closer, connection diagram No. 0.212 Protection class: IP44 Flow direction: Horizontal from the left |
Please contact us to request a price quote for Honsberg - VR-010GR007-480598, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
