Honsberg - UR3K-010GK050
| Manufacturer | Honsberg |
|---|---|
| Part Number | UR3K-010GK050 |
| Inner Code | 543931 |
| Description | Flowmeter |
| Custom Code | 85365080 |
| Technical specification | 940246 (order code: UR3K-010GK050) flow monitor Nominal size: DN 10 - G Connection type: internal thread Case: stainless steel Connection material: stainless steel Pressure resistance: PN 25 Seal: FKM Media temperature: -20... +110 °C Ambient temperature: -20... +70 °C Switching range: 3.5... 5 l/min H2O Switch head: plastic Adjustment: adjusting screw El. Connection: DIN 43650-A/ISO 4400 plug El. Contact: reed switch Contact rating: 230 V AC 1 A 50 VA Connection diagram: Closer, connection diagram No. 0.372 Protection class: IP65 Flow direction: Horizontal from left Article number: 85365080 Country of origin: Germany |
| Weight | 1 |
Please contact us to request a price quote for Honsberg - UR3K-010GK050, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
